CHANGZHOU QISHENG ELECTRONICS COMPONET FACTORY



QSR-5010 SERIES

DIMEMSIONS     Unit:mm     Tolerance:±0.5





SPECIFICATIONS



Model No

QSR-5010

Rated Voltager

12Vp-p Square Wave

Max.Allowable Voltage

30Vp-p Square Wave

Max.Rated Current

4mA at 1.0KHz/12Vp-p Square Wave

Min.Sound Pressure Level

75dB at 1.0KHz/12Vp-p Square Wave /10cm

Resonant Frequency

1.0±0.5KHz

Operating Temperature

-20℃~+60℃

Weight

4g





◆   Value appling rated voltage



Tel:+86-519-6464518     Fax: +86-519-6464189
